Pneumatic Piston Seal

Dimensions: ( I.D - O.D - Thk) Material: PU (Polyurethane). Color: Blue / Green (As Per Size and Availability) Temperature: (-20 °C To -220 °C)* Pressure Rating:(0 - 400 Bar)* Scope of application Operating pressure ≤ 16 bar Operating temperature -30 ° C to +80 ° C Sliding speed ≤ 1 m / s Media...
Product description

Dimensions: ( I.D - O.D - Thk)

Material: PU (Polyurethane).

Color: Blue / Green (As Per Size and Availability)

Temperature: (-20°C To -220°C)*


Pressure Rating:(0 - 400 Bar)*


piston seal manufacturers.jpg

Scope of application

Operating pressure ≤ 16 bar

Operating temperature -30 ° C to +80 ° C

Sliding speed ≤ 1 m / s

Media Compressed air, both oiled and oil-free

(after assembly lubrication).

PU 57.jpg

Materials

Standard: N3578, NBR compound (≈ 75 Shore A)

for low temperatures: N8602, NBR compound (≈ 70 Shore A)

for high temperatures: V8550, FKM compound (≈ 80 Shore A)

Standard: P5010, PUR-Compound (≈ 90 Shore A)

for low temperatures: P5009, PUR compound (≈ 94 Shore A)

PU 6.jpg

Installation instructions

Lip profiles profile can be easily inserted into the snapping grooves.

In order not to damage the sealing lips during assembly.

It is necessary to have sharp edges in the area of the installation space break.

The final functional dimension receives the dynamic sealing lip first

at dimensionally correct installation groove when installed.

For dry running, it is essential that on the pole closed lubricant film is maintained.

PU 4.jpg

piston seal types.jpg
